*Automatic weight sorting machine for fruits: rotary sorter (15,000 pcs/h, 5+1 grades) or linear sorter (25,000 pcs/h/lane, 7–12 grades). ±2g accuracy, low-drop design, soft cups. Gentle handling for apples, peaches, pears, citrus, avocados. Get quote.*
Precision Grading with Zero-Bruise Technology
Product Overview – Built for Fragile Fruits
Our automatic weight sorting machine is designed with gentleness as the first priority. Whether you process apples, peaches, pears, citrus, or avocados, the machine ensures minimal damage and maximum accuracy.
Protection Feature | How It Works |
|---|---|
Water flume feeding (optional) | Fruits float into the system – water acts as a natural cushion, eliminating bruising from dry dumping |
Soft-touch brushes (optional) | Ultra-soft, food-grade bristles polish without micro-scratching |
Suspended weighing | Fruit sits in deep, ergonomic carriers – no rolling or friction during weighing |
Low-drop discharge | Minimal fall height with soft landing surfaces |
✅ The result: Minimized post-sorting browning – a common problem with traditional mechanical graders.
Application – Delicate Fruits That Need Gentle Handling
Best for: Apples, peaches, pears, avocados, mangosteens, passion fruit, kiwis, plums, tomatoes, citrus, and other delicate fruits.
Two Electronic Weight Sorting Technologies
Option A – Rotary Weight Sorter (Compact, Economical)
The rotary weight sorter uses a rotating disc to feed fruit to weighing cups. It is compact and affordable, ideal for small to medium packers.
Parameter | Reference Range |
|---|---|
Capacity | 15,000 pcs/h |
Number of grades | 5+1 exits |
Weighing range | 30 – 500 g |
Accuracy | ±2 g |
Footprint | Compact (circular design) |
Best for:
Small to medium fruit packers
Limited floor space
Budget-conscious buyers
✅ Gentle handling – low drop height, soft weighing cups.
Option B – Linear Weight Sorter (High Capacity, Multi-Lane)
The linear weight sorter uses a straight conveyor belt to feed fruit to weighing cups. It offers higher capacity and more grades.
Parameter | Reference Range | Customizable |
|---|---|---|
Capacity (per lane) | 25,000 pcs/h/lane | ✅ Yes (1–4 lanes) |
Number of grades | 7 – 12 exits | ✅ Yes |
Weighing range | 20 – 500 g | ✅ Yes |
Accuracy | ±2 g | ✅ Yes |
Lane configuration | 1, 2, or 4 lanes | ✅ Yes |
Capacity by lanes:
Best for:
Large fruit packers
Export orders requiring fine grading (7–12 grades)
Integration with belt filler or packing tables
✅ Gentle handling – low drop height, soft cups, food-grade PVC belts.
Front-End: Washing (Optional)
Option
Benefit
Water flume (buoyancy-first)
Fruits float in – no bruising
Soft-touch brushes
Gentle polishing
Air blowers
Surface drying if needed
Back-End: Packing (Boxes & Cartons Only)
Option
Description
Automatic box filler
Precise, low-drop placement into cartons or boxes
Packing table
Sponge-buffered slopes – fruit rolls gently to packers
Key Advantages
Advantage
Benefit
Anti-bruise design
Reduces post-sorting browning, lowers reject rate
High accuracy
±1.5–2g – no overfilling, no giveaway
Flexible layouts
Compact circular to high-speed linear
Smart switching
PLC touch screen – save profiles for apples, pears, peaches, citrus
Frequently Asked Questions
Key questions customers usually ask before choosing this solution.
Why is this machine better for thin-skinned fruits like apples?+
Most graders use hard plastic drops. Our system uses a proprietary "Soft-Landing" mechanism and synchronized belt speeds to ensure that the fruit never experiences a high-impact fall.
Can I integrate this with my existing water tank?+
Yes. Our modular design is compatible with various water-feeding and dry-feeding systems.
